How do I measure the radius of an arc in a PDF drawing using PlanForm?

1. Click on the "Measure" Tool:

Open your PDF drawing in PlanForm and click on the"Measure" button in the toolbar to activate the measurement tools. 2. Select the "Radius" Function:

In the measurement tools menu, choose the"Radius" function. This will allow you to measure the radius of an arc in your drawing.

3. Specify the Starting Point or Arc:

• To define the radius, you have two options:
• Click to specify the starting point of the arc, or
• Click directly on the arc to define the radius.

4. Position the Comment:

After specifying the points, left-click to choose where you want the radius measurement comment to appear on the drawing.

5. View the Measurement:

Once the radius is defined, the radius measurement will pop up in the selected area. The system will display the measurement in a pop-up window.
