How do I measure the diagonal length of figures in a PDF drawing?

1. Open Measure Tool:

• Click the Measure button in the toolbar.

2. Select AlignedTool:

• Under Length Measurement, choose the Aligned option.

3. Specify Points:

• Left-click to specify the starting and ending points of the line.

4. Position Dimension Lines:

• After specifying the two points, left-click again to position the dimension lines.

5. View Measurement:

• The length measurement will pop up in the selected area.
