How do I measure the length with a complex shape in a PDF drawing?

1. Open Measure Tool:

• Click the Measure button in the toolbar.

2. Under Length Measurement, choose the Continuous

3. Specify Points:

• Left-click to specify the points of the shape.
• Continue clicking to trace the shape.

3. Finish Measurement:

• Right-click to complete the measurement.

4. View Total Length:

• The total length measurement will appear in the selected area.
